Tysso TD-650 is a light-weight 2D Data-Matrix barcode imager. With the compact-light-weight housing, TD-650 is ideal for performance-oriented applications, especially for industry demands: retail, chain stores, healthcare, inventory, logistics, etc.
By adapting high-sensitivity CMOS imaging technology, TD-650 offers reliable scanning accuracy even in less-satisfied scanning environments. In addition, TD-650 allows users to capture wrinkled, damaged or poor-conditioned barcodes and OCR fonts. Those merits ensure TD-650 a reliable data management device for you.
To ensure high-quality data accessing operations, TD-5208 is your best choice for 24/7 works and ensure scanning barcode to be an easy job.
- High-Sensitivity CMOS Image Sensor
- Resolution: 752 x 480
- 1D & 2D barcodes
- Suitable for various applications, especially industrial production
- Simple Operation with programmable configuration
- USB Interface (Optional RS232)
- Operates under low-light environments
| Sensor Type | 752 x 480 CMOS Image Sensor |
| Light Source | LED (622nm~628 nm) |
| Scan Angle | 60o (Horizontal) / 60o (Vertical) |
| Scan Pattern | Area |
| Rotation Sensitivity | 360 around the optical Axis |
| Minimum Element Width | 1D Barcodes: 35 mm |
| 2D Barcodes: 45 mm | |
| Matrix Barcodes: 45 mm | |
| Contrast Ratio | 30% minimum |
| Interface | USB |
| Serial (RS232) On Order | |
| Readable Bar Code Symbologies (1D) | Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ISBN, Code 93, UCC/EAN-128, GS1 Databar, etc |
| Readable Bar Code Symbologies (2D) | PDF417, QR Code (Model 1/2), Data Matrix (ECC200, ECC000, 050, 080, 100,140), Aztec, Maxicode, etc. |
| Power Input | 5V DC |
| Material | ABS |
| Colour | Black |
| Shock Resistence | 1m onto concrete |
| Weight | 185 g (with cable) |
| Dimensions (LxWxH) | 167.5mm x 72mm x 78mm |
| Colour | Black |
|---|---|
| Scanner | CMOS |
| Scan Engine | 2D |
| Type | Hand-Held, Wired |
| Interface | Serial, USB 2.0 |
